Descripción
- Classic Sontec 250 design.
- All-discrete analog circuit.
- Clean & natural sounding.
- 5 true parallel bands on each channel.
- 56V linear power supply.
- Customiser available.
- 6 dB version available in customiser.
Did anyone say ANALOG?
HVC250 is built in the expensive way. The 14 independent high-voltage opamps inside outperform the traditional IC opamps at bandwidth and dynamics. The electric components are made by Nikon, Motorola, Philips, and ON. The all-discrete circuit boards preserve the beauty of analog equipment, while this modern-day design makes it possible to stay clean at the output.
As powerful as a tank
A 56V high-voltage linear power supply unit is essential to HVC250’s solid, detailed, clear, and spacious sound quality. It helps handle a higher dynamic range, offers more headroom, and reduces noise effectively. While others are drifting away, we stick to this time-tested solution with even extra expense on a more effective cooling system.
Effective and fun
Each independent band offers a range of ±12dB (hardware maximum at ±16dB) and comes with its own bypass. They highly overlap each other. With Q between 0.6 and 4, you could perform surgical tricks on any track. With shelf option at air and sub bands, you can do the high & low stuff which is inherited well from its ancestor. Despite having a variety of options, users tend to feel engaged and are able get lovely sound within a few tweaks.
Handcrafted & verified by human, for human.
Before it gets shipped, 2 real mixing engineers will test it and sign their names, so will every craftsman who participated in the making. Boutique-grade craftsmanship makes no effort in producing many.
Customise to suit your studio style.
Switch knobs & panel board with our online customiser.
Custom panel design available upon request.
Specs
| Frequency range |
15Hz – 25kHz
|
| SNR |
left: -97.092 dBV
right: -96.021 dBV
|
| Form factor |
2 channels, 5 bands: fully parametric
|
| LF |
15Hz – 800Hz
Q: 0.67 – 4 or shelf
12dB boost/cut
|
| LMF | 15Hz – 800Hz Q: 0.67 – 4, 12dB boost/cut |
| MF | 160Hz – 8kHz Q: 0.67 – 4 12dB boost/cut |
| HMF | 450Hz – 25kHz Q: 0.67 – 4 12dB boost/cut |
| HF | 450Hz – 25kHz Q: 0.67 – 4 or shelf 12dB boost/cut |
| Distortion (left & right channel off) | 0.0008% |
| Distortion (left & right channel on) | 0.0015% (20Hz – 20kHz) |
| Chassis size (H×W×D) | 4’3.2″ (130mm) × 13’3″ (404mm) × 8’4.1″ (254mm) |
| Panel Size (H×W) | 4’4.2″ (133mm) × 15’10» (483mm) |
| Voltage Selector | 110V, 220V |
